Basic Info.
Model NO.
QW384-140-FC
Charger Application
Standard Battery
Nominal Voltage
43.8V
Charger Style
Intelligent Charger
Compatible Battery Type
36-Volt
Size
215*100*55mm
Certification
KC, PSE, RoHS, CB, CE, SAA Rcm Ukca Bsmi Ices
Socket Type
Au/EU/UK/Us Plug
Recyclable
Recyclable
Input Voltage
100-240VAC 50/60Hz
Color
Black
Transport Package
Corrugated Paper Packing Box
Specification
Weight: 1600± 10g(only body)
Trademark
QUAWIN/OEM
Origin
Shenzhen
HS Code
850431900
Production Capacity
50000 Pieces
Product Description
Quick Detail:
Brand Name:QUAWINModel Number:QW384-140-FC
Use:12S 36V/38.4V Lifepo4 battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 43.8V
Color:Black/Silver
Shell Material:Aluminium alloy
Additional features:CANBUS Communication Protocol
Input voltage:100-240VAC 50/60Hz with PFC
Output voltage:43.8V
Output current:14a(Max)
Output power:613.2W
Charge mode:CC-CV(Constant Current-Constant Voltage)
Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized
Packaging & Delivery :
12pcs/Carton
Carton size: 535*315*280mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order
Carton size: 535*315*280mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order
Specifications:
12S 36V/38.4V Lifepo4 battery pack
Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=90%
• Operating temperature:-20ºC ~ 45ºC
• Storage temperature:-40ºC ~ 85ºC
• Operating humidity:5%~90%RH
Specification:
• Input: 100-240VAC 50/60Hz with PFC
• Output: DC 43.8V
• Charging current: 14a(Max)
• Dimensions (mm): 215*100*55
• Weight: 1600±10g(only body)
Safety protections:
• Over current protection
• Over voltage protection
• Short circuit protection
• Reverse polarity protection
• Anti- revert current protection
• Anti-spark protection
LED Indicator:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH
Call us to know more details datasheet
| Typical Product Model | |||||
| Model | Input Voltage(V) | Battery Voltage(V) | Charging Voltage(V) | Charging Current(A) | |
| QW128-300-FC | LiFePO4 | AC 100~264V | 12.8(4S) | 14.6 | 30 |
| QW160-300-FC | 16(5S) | 18.25 | 30 | ||
| QW192-270-FC | 19.2(6S) | 21.9 | 27 | ||
| QW224-230-FC | 22.4(7S) | 25.55 | 23 | ||
| QW256-200-FC | 25.6(8S) | 29.2 | 20 | ||
| QW288-180-FC | 28.8(9S) | 32.85 | 18 | ||
| QW320-160-FC | 32(10S) | 36.5 | 16 | ||
| QW352-150-FC | 35.2(11S) | 40.15 | 15 | ||
| QW384-140-FC | 38.4(12S) | 43.8 | 14 | ||
| QW416-125-FC | 41.6(13S) | 47.45 | 12.5 | ||
| QW448-120-FC | 44.8(14S) | 51.1 | 12 | ||
| QW480-110-FC | 48(15S) | 54.75 | 11 | ||
| QW512-100-FC | 51.2(16S) | 58.4 | 10 | ||
| QW544-095-FC | 54.4(17S) | 62.05 | 9.5 | ||
| QW576-090-FC | 57.6(18S) | 65.7 | 9 | ||
| QW608-085-FC | 60.8(19S) | 69.35 | 8.5 | ||
| QW640-080-FC | 64(20S) | 73 | 8 | ||
| QW672-080-FC | 67.2(21S) | 76.65 | 8 | ||
| QW704-075-FC | 70.4(22S) | 80.3 | 7.5 | ||
| QW736-070-FC | 73.6(23S) | 83.95 | 7 | ||
| QW768-070-FC | 76.8(24S) | 87.6 | 7 | ||
| QW148-300-LC | Lithium | 14.8(4S) | 16.8 | 30 | |
| QW259-200-LC | 25.9(7S) | 29.4 | 20 | ||
| QW370-140-LC | 37(10S) | 42 | 14 | ||
| QW481-100-LC | 48.1(13S) | 54.6 | 10 | ||
| QW629-080-LC | 62.9(17S) | 71.4 | 8 | ||
| QW740-070-LC | 74(20S) | 84 | 7 | ||
